John Deere 330 Compact Utility Tractor – John Deere 330 Compact Utility Tractor is a compact-sized utility tractor that features a 3-cylinder engine from Yanmar. The Yanmar engine is a type of 3TN66UJ that burns diesel as its main source of power. The displacement capacity of the vehicle is 658cc. At its maximum operating speed at around 3600 RPM, the engine can produce up to 16 hp or about 11.9 kW of power.
The transmission system that is being used on the John Deere 330 Compact Utility Tractor is the hydrostatic transmission. Meanwhile, the 16hp Yanmar engine is also equipped with a 4×2 2WD design for the chassis. The oil capacity of the engine is around 2.4 L. For the braking system, the vehicle uses an integral mechanical shoe to stop the vehicle. An open operator station design is used on the operator cab to add more comfort while operating the vehicle.
The fuel tank of the John Deere 330 Compact Utility Tractor can contain up to 17 L of diesel, which is about 4.5 US gallons. Meanwhile, the hydraulic system will also require the usage of at least 4.7 L of hydraulic fluid. The operator can also opt to get various mower decks with a mid-mount mechanism to be used along with the vehicle. The mower decks are available with different blade sizes, including the 38-inches, 46-inches, and 50-inches.
So, now that you have found out about the John Deere 330 Compact Utility Tractor as well as its features, you can also learn more about the complete specifications of the vehicle by going through each point below this article. You will be able to find out about the tractor price, available spare parts, user reviews, serial numbers, and other aspects of the vehicle.
John Deere is a brand that is used on machinery produced by Deere & Company. Deere & Company itself was founded by a businessman named John Deere in 1837. Currently, the headquarters of the company is located in Moline, Illinois. They serve and market their products around the world. In 2020, the company marked a revenue of around US$39 billion. With more than 69,000 employees working for the company, they have now become one of the most valuable heavy machinery manufacturers in the world.
John Deere 330 Price
- John Deere 330 Original Price: $2,999*
Related Post
- John Deere LT160
- John Deere LT180
- John Deere LX172
- John Deere LX188
- John Deere LX279
- John Deere STX38 Black Deck
- John Deere X360
- John Deere X595
- John Deere 155C
- John Deere 175 Hydro
John Deere 330 Serial Number
| 1986 | 360001 |
| Final | 420000 |
John Deere 330 Specification
| JOHN DEERE 330 ENGINE | |
| Engine | Yanmar 3TN66UJ diesel 3-cylinder liquid-cooled |
| Displacement | 658 cc 40.2 ci |
| Bore/Stroke | 2.60×2.62 inches 66 x 67 mm |
| Power | 16 hp 11.9 kW |
| Air cleaner | dry |
| Compression | 22.4 |
| Rated RPM | 3635 |
| Oil capacity | 2.5 qts 2.4 L |
| Coolant capacity | 2.9 qts 2.7 L |
| JOHN DEERE 330 CAPACITY | |
| Fuel | 4.5 gal 17.0 L |
| Hydraulic system | 1.25 gal 4.7 L |
| JOHN DEERE 330 MECHANICAL | |
| Chassis | 4×2 2WD |
| Steering | manual |
| Brakes | integral mechanical shoe |
| Cab | Open operator station. |
| Transmission | hydrostatic |
| JOHN DEERE 330 TRANSMISSION | |
| Transmission | Sundstrand Series 15 Model 90 |
| Type | shaft-driven hydrostatic |
| Gears | infinite forward and reverse |
| Oil capacity | 6.5 qts 6.2 L |
| JOHN DEERE 330 HYDRAULICS | |
| Capacity | 1.25 gal 4.7 L |
| Valves | 1 |
| JOHN DEERE 330 PTO | |
| Rear PTO | independent* |
| Clutch | electric |
| Rear RPM | 2000 |
| Front PTO | independent |
| Clutch | electric |
| Front RPM | 3450 |
| JOHN DEERE 330 DIMENSIONS | |
| Wheelbase | 46 inches 116 cm |
| Length | 69.5 inches 176 cm |
| Width | 43.3 inches 109 cm |
| Height | 44.5 inches 113 cm |
| Weight | 900 lbs 408 kg |
| Front tread | 32 inches 81 cm |
| Rear tread | 30.5/32.8 inches 77/83 cm |
| JOHN DEERE 330 TIRES | |
| Lawn/turf front | 16×6.50-8 |
| Lawn/turf rear | 23×10.50-12 |
| JOHN DEERE 330 ELECTRICAL | |
| Charging system | alternator |
| Charging amps | 20 |
| JOHN DEERE 330 BATTERY | |
| Number | 1 |
| Volts | 12 |
John Deere 330 Attachments
| 38″ MOWER DECK | |
| Type | mid-mount John Deere |
| Cutting width | 38 inches 96 cm |
| 46″ MOWER DECK | |
| Type | mid-mount John Deere |
| Cutting width | 46 inches 116 cm |
| 50″ MOWER DECK | |
| Type | mid-mount John Deere |
| Cutting width | 50 inches 127 cm |
John Deere 330 Review Video
Related Post
- John Deere 322
- John Deere 445
- John Deere 855
- John Deere 970
- John Deere 2010
- John Deere 2020
- John Deere D130
- John Deere GT245
- John Deere L108
Conclusion
That was all that we can say about the John Deere 330 Compact Utility Tractor along with the features offered by the vehicle. If you still have any questions about the vehicle, you can fill in the comment box below and type in your questions. You can also compare the vehicle with other tractors.
