Oliver 77 Row-Crop Tractor – Oliver 77 Row-Crop Tractor is a tractor that features a gasoline engine produced by Waukesha-Oliver. The engine has 6 cylinders as well as a vertical L-head. To maintain a proper temperature inside the engine, the vehicle uses a liquid-cooling mechanism to handle the potential heat from the powerful engine. With a maximum speed rating of 1600 RPM, the engine can produce up to 32.89 hp or about 24.5 kW. Meanwhile, the displacement is around 3.2 L.
The chassis that is used on the Oliver 77 Row-Crop Tractor is the conventional 4×2 2WD chassis. For the safety of vehicle operation, the operator can use the differential mechanical drum brakes to stop the tractor. Depending on the type of attachment used on the vehicle, the weight of the tractor ranges from 4200 to 8200lbs. Meanwhile, the oil capacity of the engine is around 7.8 L. The transmission system that is used on the tractor allows the operator to access 6 forward gears and 2 reverse gears.
There are three types of engines that can be used on the Oliver 77 Row-Crop Tractor, including a gasoline engine, a diesel engine, or an LP gas engine. All those engines have a similar design with a 6-cylinder and a capacity of 3.2 L produced by Waukesha-Oliver. The fuel tank is able to accommodate up to 62.5 L of fuel. The steering uses a manual steering mechanism and the driver seat has been designed with an open operator station design.
So, now all you need to do is to find out more about the current price of the Oliver 77 Row-Crop Tractor along with information about the basic specifications and user reviews. The reviews are important to ensure that the tractor works properly, especially on handling heavy-duty works on the field. Also, you can compare the specifications of this vehicle to similar products from different manufacturers.
Oliver Farm Equipment Company is a manufacturer of farm equipment originated from America. The company was established when four companies formed the merger in 1929. But, the company was then purchased by White Motor Corporation in 1960. They produce various tractors that are popular in the late 50s. Aside from that, they also manufacture nonagricultural products, including forklifts, crawlers, power units, and others to be sold to other companies.
Oliver 77 Price
- Oliver 77 Original Price: $3,000 USD (1954)
Oliver 77 Serial Number
| 1948 | 320001 |
| 1949 | 320241 |
| 1950 | 327901 |
| 1951 | 337243 |
| 1952 | 347904 |
| 1953 | 3500001 |
| 1954 | 4501667 |
| Final | 4504470 |
Oliver 77 Specification
| OLIVER 77 GASOLINE ENGINE | |
| Engine | Waukesha-Oliver gasoline 6-cylinder liquid-cooled vertical I-head 193.9 ci [3.2 L] |
| Bore/Stroke | 3.3125×3.75 inches [84 x 95 mm] |
| Air cleaner | oil bath |
| Compression | 6.75:1 |
| Rated RPM | 1600 |
| Firing order | 1-5-3-6-2-4 |
| Oil capacity | 8 qts [7.6 L] |
| Coolant capacity | 13.5 qts [12.8 L] |
| OLIVER 77 DIESEL ENGINE | |
| Engine | Waukesha-Oliver diesel 6-cylinder liquid-cooled vertical I-head 193.9 ci [3.2 L] |
| Bore/Stroke | 3.3125×3.75 inches [84 x 95 mm] |
| Air cleaner | oil bath |
| Compression | 15.75:1 |
| Rated RPM | 1600 |
| Firing order | 1-5-3-6-2-4 |
| Starter volts | 12 |
| Coolant capacity | 18 qts [17.0 L] |
| OLIVER 77 LP GAS ENGINE | |
| Engine | Waukesha-Oliver LP gas 6-cylinder liquid-cooled 193.9 ci [3.2 L] |
| Bore/Stroke | 3.3125×3.75 inches [84 x 95 mm] |
| Air cleaner | oil bath |
| Compression | 6.75:1 |
| Rated RPM | 1600 |
| Starter volts | 6 |
| Coolant capacity | 18 qts [17.0 L] |
| OLIVER 77 CAPACITY | |
| Fuel | 16.5 gal [62.5 L] |
| OLIVER 77 POWER | |
| Plows | 2-3 |
| Drawbar (tested) | 32.89 hp [24.5 kW] |
| Belt (tested) | 37.17 hp [27.7 kW] |
| OLIVER 77 MECHANICAL | |
| Chassis | 4×2 2WD |
| Steering | manual |
| Brakes | differential mechanical drum |
| Cab | Open operator station. |
| OLIVER 77 TRANSMISSION | |
| Type | unsynchronized gear |
| Gears | 6 forward and 2 reverse |
| Clutch | dry disc |
| OLIVER 77 BELT PULLEY | |
| Diameter | 12 inches [30 cm] |
| Width | 7.25 inches [18 cm] |
| RPM | 992 |
| Speed | 3,080 ft/min [938.78 meters/min] |
| OLIVER 77 PTO | |
| Rear RPM | 540 |
| OLIVER 77 DIMENSIONS | |
| Weight (operating) | 4,207 lbs [1908 kg] (gas) |
| 4,502 lbs [2042 kg] (diesel) | |
| Weight (ballasted) | 8,203 lbs [3720 kg] |
| Wheelbase | 90.75 inches [230 cm] |
| Length | 139.25 inches [353 cm] |
| Height | 75 inches [190 cm] |
| Ground clearance | 24.9 inches [63 cm] |
| Front tread | 7.5/12.6 inches (tricycle) [19/32 cm]60 to 89.75 inches (wide-front) [152 to 227 cm] (wide-front) |
| Rear tread | 60 to 92.5 inches [152 to 234 cm] |
| OLIVER 77 TIRES | |
| Ag front | 5.50-16 |
| Ag rear | 10-38 |
| 11-38 | |
| 12-38 | |
Oliver 77 Review Video
Conclusion
We hope that this article regarding the Oliver 77 Row-Crop Tractor can make you understand about the aspects of this particular tractor. Remember, only get the unit if you can be sure that the engine type and features are suitable for the type of farming works is you want to do.
