With its outstanding black and orange color, Kubota B2620 Compact Utility Tractor is ready to be used to handle your big lawn jobs. It is a big machine, with lots of benefits that you can get from. The machine can also be considered powerful. If you are curious about the specification of this Kubota tractor, make sure to read through the specification below.
As the first topic, let’s take the engine into our talk. Kubota B2620 Compact Utility Tractor is using the self-made 3-cylinder Kubota D1105 engine with 1.1 L of displacement (equal to 68.5 ci). This tractor is using liquid coolant to cool down the machine and it works at rated rpm of 2,500 to produce maximum power of 25 HP (equal to 18.6 kW).
In terms of fuel, Kubota B2620 Compact Utility Tractor is using diesel as its main and only usable fuel type. You can fill the fuel tank full of 6.6 gallons (equal to 25.0 L). With such capacity, you can work with the tractor for a relatively long time.
Onto its mechanical aspects, you can expect a 4×4 MFWD 4WD chassis from this tractor. The tractor is using hydrostatic power steering and a wet disc system as its braking system. You can also use two-post foldable ROPS; and there is also sunshade available, but you can opt to roll it when unused.
What about its transmission? Regarding it, expect a hydrostatic transmission type with 3-range forward and reverse transmission gears. That said, you can expect a various maximum speed for both forward and reversed movement.
As for the tractor’s maximum movement, Kubota B2620 Compact Utility Tractor can go with 3.7-12.6 miles per hour for forward movement (equal to 6.0-20.3 km per hour). While for reversed movement, you can expect it to go as fast as 3.0-10.0 miles per hour (equal to 4.8-16.1 km per hour).
What about the price? Kubota B2620 Compact Utility Tractor may not be manufactured anymore. But you can get a secondhand version of it. That said, it is safer to understand its specification and also the original price of the tractor. Per 2011, the tractor is priced $13,888 for a unit.
Kubota B2620 Tractor Price in the USA
- Original Price: $13,888 (2011)
- Kubota B2620 Tractor Serial Numbers: Not Available
Related Post
- Kubota Tractors Prices USA
- Kubota BX23S
- Kubota BX25
- Kubota G5200
- Kubota L2501
- Kubota B2601
- Kubota B2650
- Kubota B3300SU
- Kubota B5200
Kubota B2620 Specification
KUBOTA B2620 ENGINE | |
Engine | Kubota D1105 diesel 3-cylinder liquid-cooled 68.5 ci [1.1 L] |
Bore/Stroke | 3.1×3.1 inches [79 x 79 mm] |
Power (gross) | 26 hp [19.4 kW] |
Air cleaner | dual paper elements |
Rated RPM | 2800 |
Starter volts | 12 |
Oil capacity | 3.2 qts [3.0 L] |
Coolant capacity | 4.1 qts [3.9 L] |
KUBOTA B2620 TRANSMISSION | |
Type | hydrostatic |
Gears | infinite (3-range) forward and reverse |
Oil capacity | 16 qts [15.1 L] |
KUBOTA B2620 3 POINT HITCH | |
Rear Type | 1 |
Rear lift (at ends) | 1,356 lbs [615 kg] |
Rear lift (at 24″/610mm) | 1,058 lbs [479 kg] |
KUBOTA B2620 PTO | |
Rear PTO | live |
Rear RPM | 540/960 (1.375) |
Engine RPM | 540@2773 960@2722 |
Mid PTO | optional |
Mid RPM | 2500 |
Engine RPM | 2500@2750 |
KUBOTA B2620 POWER | |
Engine (gross) | 26 hp [19.4 kW] |
PTO (claimed) | 19 hp [14.2 kW] |
KUBOTA B2620 HYDRAULICS | |
Type | open center |
Capacity | 4 gal [15.1 L] |
Valves | 1 or 2 |
Pump flow | 4.7 gpm [17.8 lpm] |
Total flow | 8.3 gpm [31.4 lpm] |
Steering flow | 3.6 gpm [13.6 lpm] |
KUBOTA B2620 CAPACITY | |
Fuel | 6.6 gal [25.0 L] |
Hydraulic system | 4 gal [15.1 L] |
KUBOTA B2620 MECHANICAL | |
Chassis | 4×4 MFWD 4WD |
Differential lock | rear standard |
Steering | hydrostatic power |
Brakes | wet disc |
Cab | Two-post foldable ROPS. Sunshade optional. |
KUBOTA B2620 DIMENSIONS | |
Weight | 1,554 lbs [704 kg] |
Wheelbase | 61.5 inches [156 cm] |
Length | 95.1 inches [241 cm] |
Width | 49 inches [124 cm] |
Ground clearance | 12.8 inches [32 cm] |
Front tread | 32.1 inches [81 cm] |
Rear tread | 37.4 inches [94 cm] |
4WD turn radius | 6.9 feet [2.1 m] (with brake) |
KUBOTA B2620 TIRES | |
Standard tires (ag) | Front: 7-12. Rear: 11.2-16 |
Optional tires (ag) | Front: 6.00-12. Rear: 9.5-16 |
Lawn/turf front | 22×8.50-12 |
23×8.50-12 | |
Lawn/turf rear | 33×12.50-15 |
Industrial front | 23×8.50-12 |
Industrial rear | 12-16.5 |
KUBOTA B2620 ELECTRICAL | |
Ground | negative |
Charging system | alternator |
Charging amps | 14.5 |
Kubota B2620 Attachments
54″ MOWER DECK | |
Type | mid-mount Kubota RCK54 |
3-blade | |
Cutting width | 54 inches [137 cm] |
Weight | 300 lbs [136 kg] |
Cut height | 1 to 4 inch [2 to 10 cm] |
60″ MOWER DECK | |
Type | mid-mount Kubota RCK60 |
3-blade | |
Cutting width | 60 inches [152 cm] |
Cut height | 1 to 4 inch [2 to 10 cm] |
LOADER | |
Loader type | Kubota LA364 |
Height (to pin) | 78.6 inches [199 cm] |
Clearance, dumped bucket | 60.9 inches [154 cm] |
Dump reach | 22.7 inches [57 cm] |
Dump angle | 40 |
Rollback angle | 25 |
Breakout force (at pin) | 2,144 lbs [972 kg] |
Breakout force (at 500mm) | 1,520 lbs [689 kg] |
Breakout force (bucket) | 1,741 lbs [789 kg] |
Lift to full height (at pin) | 952 lbs [431 kg] |
Lift to full height (at 500mm) | 661 lbs [299 kg] |
Bucket width | 50 inches [127 cm] |
Raise time to height | 3.7 s |
Bucket dump time | 1.9 s |
Lowering time | 2.7 s |
Rollback time | 2.6 s |
BACKHOE | |
Backhoe type | Kubota BH65 |
Digging depth | 80.1 inches [203 cm] |
2-Foot flat digging depth | 78.8 inches [200 cm] |
8-Foot flat digging depth | 56.4 inches [143 cm] |
Reach from pivot | 108.9 inches [276 cm] |
Loading height | 64.5 inches [163 cm] |
Bucket force | 2,585 lbs [1172 kg] |
Dipperstick force | 1,687 lbs [765 kg] |
Kubota B2620 Tractor Review Video
Related Post
- Kubota B6000
- Kubota B7200
- Kubota BX25D
- Kubota BX1500
- Kubota BX1870
- Kubota BX2230
- Kubota BX2680
- Kubota L175
- Kubota M6800
- Kubota M7060
Conclusion
Well, that’s the information related to Kubota B2620 Compact Utility Tractor. If you have any inquiries regarding the tractor, don’t hesitate to ask us through the comment section below. We will try to respond to your queries as soon as possible. Thank you for visiting and stay tuned for more contents alike.
